Advanced water heating system with lowest fuel consumptions. In terms of recurring
running cost, it is cheaper than any other systems. Most European countries adopt this system.
🌀 Modern Storage type water Heater.
🌀 Hot Water in just 10 Minutes & Multi floor hot water connection.
🌀 Retains heat for 8-10 hrs. also, suitable for hard water.
🌀 It works on Wood, Charcoal, Coconut shah, kernels and Agricultural waste.
🌀 Rust proof coating & 5 Years Warranty.
🌀 No Electricity save your Money.
Suitable for
SURYA 1000 L Wood Fired Water Heater is Suitable for Domestic and
Commercial Purpose. Dairy farms, Resorts, Lodges, Pharmaceutical industry, manufacturing
plants, Food and Beverage industry, Textile Industry, Factories and etc.
Some of Our Customer’s
Info Institute of Engineering, Patanjali Haridwar, The Arya Vaidya Sala Velanthavalam,
Poomex, Deccan Pumps, ABT Industries.
The Petals- Coorge
The Gurupriya – Kodaikanal
Kings land- Karnataka
Safety Features
🔘 SURYA Wood Fired Water Heater Withstand a Pressure up to 10kg/cm2. Tested
with 12.5 Kg air Pressure.
🔘 SAFTY VALVE
Product Details
💠 50 mm x 32 Glass wool Insulation
💠 Boiler Inner tank Mild Steel & Outer Cover SS
💠 Temperature Meter
💠 Safety Valve attached
💠 Tested for 12.5 kg air pressure
Accessories
Stand Ash drawer
Fire bar Door
Chimney cap Temperature gauge
Spring type enclosed safety valves User manual
Technical Details
🔹 Model: 1000 L
🔹 Top circle: 6 mm
🔹 Outer tank: 5 mm
🔹 Inner tank: 12 mm
🔹 Diameter: 48 inches
🔹 Height: 12 feet
🔹 Fuel Required: 55 kg @max load
🔹 Total weight: 850 kg
🔹 Inlet pipe: 2.6 inch
🔹 Outlet pipe: 2.6 inch
🔹 Air vent: 3/4 inch
🔹 Drainage: 1.6 inch
🔹 Place required: 4x4 feet
🔹 Exhaust pipe : 10 feet
🔹 Hot Water 🕰◻: 60°C in 20 Minutes (1 L of 60°C Hot Water is Mixed with 2L
of Cold Water for Bathing)
Cost Comparison of Wood fired Water Heater over other
�
� Systems: Per person need 20L hot water for bathing
�
� Wood Fired Water Heater (home waste): Zero Cost
�
� Electrical Water Heater (Electricity): 12Rs
�
� Solar water Heater (Electric breakup): 5Rs
�
� Charcoal: 8Rs
�
� Kerosene: 9Rs
�
� LPG: 12Rs
�
� Natural Gas: 6Rs
How to maintain Boiler for more life span?
❖ Always Keep Boiler dry
❖ Don’t place your Shampoo, Soap, detergents and etc. on the top of boiler.
❖ Plumbing connection has to be done Without leaking.
❖ Don’t use plastic.
❖ Do not fit non return valve (NRV)
❖ Clean the waste, Ash.
☑ Dirty, Rusty or Smelly Water
If your water is smelling off, it is always an indicator of some kind of bacteria growth. You will
need to flush your tank.
☑ More Time & Fuel
It is almost always an indicator of some kind of Dust blockage. Your will need to clean Boiler
Exhaust pipe.
Why Wood fired water heater is best over other systems?
�
� Wood-fired water heater runs regardless of the weather, whereas a solar water
heater cannot run on overcast, wet, or foggy days.
�
� When hard water is present, wood-fired water heaters perform best; solar water
heaters are not appropriate for hard water.
�
� Wood-fired water heater is more affordable than an electric one. Operating cost of
electric water is high.
�
� Wood Fired water heater helps in muscle relaxation & recovery, relief from
